Quick answer
A kiln support-roller bearing that becomes hotter after alignment work should be treated as a post-intervention load-distribution problem until evidence shows otherwise. Compare bearing temperature, roller axial position, tyre contact pattern, roller slope/skew, lubrication condition and kiln axial behavior before and after the alignment. The most important question is whether the work changed how load is shared across the roller pair or introduced abnormal thrust, edge loading or bearing preload.
Problem / job
One support-roller bearing or one side of a pier heats more than before after alignment adjustment.
Evidence
Capture bearing temperatures, roller/tyre contact, axial position, support-roller adjustment record, kiln thrust behavior, lubrication status and vibration.
Decision
Separate changed load distribution or axial thrust from lubrication/cooling issues, sensor error and unrelated bearing damage.
As-found evidence capture
Trend temperatures from startup to steady kiln operation and compare both bearings on the adjusted roller, the opposite roller at the same pier and historical values from before alignment. Record kiln speed, production rate and shell/tyre temperature because these affect operating geometry.
Review the exact alignment movement: which roller moved, by how much and in which direction. Preserve the adjustment record; without it, the temperature change cannot be linked reliably to the intervention.
Post-alignment go/no-go checklist
- Verify the bearing-temperature signal independently where practical.
- Document exactly which roller moved, the direction and amount of movement, and the cold/hot condition used for the adjustment.
- Compare both bearing ends on the adjusted roller with the opposite roller at the same pier and the neighboring pier.
- Check lubrication level/flow, seals and any lines disturbed during alignment work.
- Assess tyre/roller contact width, edge loading and witness marks at operating temperature only through approved remote or non-intrusive observation from a safe location; defer hands-on inspection until shutdown, hazardous-energy isolation and lockout/tagout are verified.
- Trend kiln axial position and thrust-contact behavior so added roller skew is not mistaken for a simple radial-load issue.
- Only consider another roller move after the temperature, contact and axial evidence identify the load path that changed.
Go/no-go rule: a hot bearing by itself is not an alignment instruction. Prove whether the intervention changed load sharing, axial steering, lubrication or the measurement first.
Seven-step diagnostic workflow
1. Verify the temperature measurement
Cross-check the installed sensor with a suitable independent method where practical. Confirm the sensor has not been disturbed, loosened or relocated during alignment work.
2. Check lubrication immediately
During authorized kiln operation, verify lubricant supply, level, flow and temperature using installed instrumentation, approved remote observations and existing maintenance records from outside moving-equipment exclusion zones. Do not approach, open, disconnect or touch lubrication lines, seals or bearing housings while equipment is operating. Inspect lubricant condition, disturbed piping, seals and fittings physically only after shutdown, control of stored hydraulic and thermal energy, and verified lockout/tagout in accordance with site and OEM procedures. If lubrication is uncertain or the bearing continues to heat, follow the plant’s approved alarm, shutdown and escalation criteria rather than continuing operation without a verified safe condition.
3. Compare load sharing across the pier
Review roller/tyre contact and available load indicators using approved non-intrusive observations, installed instruments and existing records from a safe location. A roller adjustment can transfer load from one support to another or concentrate load toward one bearing. Assess changes in contact width, edge loading or surface marks from authorized remote observations or shutdown inspection records. Do not approach, mark, touch or measure rotating parts; any hands-on contact inspection requires shutdown and verified hazardous-energy isolation and lockout/tagout under site and OEM procedures.
4. Review roller skew and axial behavior
Check kiln axial position and thrust-roller contact. Excessive skew can create axial force through the roller and increase bearing load even when radial alignment appears acceptable.
5. Check bearing internal condition and clearance
If temperature remains abnormal after load and lubrication checks, use available condition-monitoring data to evaluate possible clearance, preload, housing or bearing damage. Any physical bearing or housing inspection, clearance measurement or disassembly must follow shutdown, control of stored mechanical, hydraulic and thermal energy, verified lockout/tagout and the bearing/roller manufacturer’s approved procedure. Do not undertake hands-on checks near a rotating kiln.
6. Correlate with shell and tyre thermal condition
Alignment geometry can change as the kiln heats. A condition that looks acceptable cold may shift at operating temperature. Compare temperature rise with shell/tyre heating and allow for the plant’s established hot-alignment criteria.
7. Verify correction over a full thermal cycle
After any justified adjustment, trend the bearing through startup and steady production. Confirm stable temperature, acceptable contact pattern, controlled axial behavior and no abnormal vibration.
Evidence-to-decision table
| Evidence | Likely direction | Next check |
|---|---|---|
| Heating started immediately after roller move | Load/skew change | Adjustment record, contact and axial behavior |
| Both bearings on same roller heat | Higher roller load or lubrication issue | Load sharing and lubrication supply |
| One bearing heats while opposite side remains normal | Axial/preload/local bearing issue | Skew, clearance and housing |
| Temperature rises only as kiln reaches hot condition | Thermal geometry shift | Hot alignment/contact pattern |
| Temperature signal conflicts with local checks | Sensor/measurement issue | Sensor installation and verification |
Reconstruct the alignment change as an engineering event
Do not troubleshoot from the final roller position alone. Reconstruct the intervention: original bearing temperatures, original tyre/roller contact, the exact roller movement, cold-versus-hot measurement condition, kiln axial position before and after, and any simultaneous lubrication or housing work. A small roller move can change both radial load sharing and axial steering force. If the temperature rise started immediately after the intervention, compare the affected bearing with its opposite bearing and with the neighboring pier to see whether the load was transferred rather than eliminated.
Review the tyre/roller contact band at a representative thermal condition using approved, non-intrusive observation or existing operating records from a safe location outside moving-equipment exclusion zones. Do not approach, touch, mark or measure rotating kiln components during operation. Any hands-on contact inspection or marking must be performed only after shutdown, verified hazardous-energy isolation and lockout/tagout under site and OEM procedures. Edge contact, a narrowed contact band or a changed polished zone can support a load-distribution hypothesis; combine this with vibration and axial-position evidence rather than using a single contact mark to justify another roller move.
Use temperature differences, not a single hot number
Trend both bearing ends on the same roller and the equivalent bearings on adjacent supports. A common temperature rise across several bearings can point toward lubricant temperature, ambient condition or higher kiln load, whereas one bearing separating from the group after alignment deserves closer attention to local thrust, clearance and housing condition. Record lubricant supply temperature separately where possible so bearing-metal heating is not confused with a hotter oil circuit.
If a corrective adjustment is required, change one controlled variable at a time and preserve the before/after evidence. Repeated trial moves without a documented geometry basis can shift the load to another bearing and make the original cause harder to identify.
Return-to-service acceptance criteria
Accept the alignment condition when support-roller bearing temperatures stabilize within the approved baseline, lubrication is normal, tyre/roller contact is acceptable, kiln axial behavior is controlled and vibration shows no new abnormal component. Use plant and OEM criteria for actual bearing-temperature and alignment limits.
Common mistakes
Do not move a support roller again solely because a bearing is hot. Do not ignore the exact previous alignment movement. Do not judge contact only when the kiln is cold if the problem occurs hot. Do not compensate for poor load sharing with extra lubricant. Finally, treat roller alignment and kiln axial behavior as a coupled system rather than isolated measurements.
