Quick answer
If a clinker-cooler crusher shows current spikes while clinker size appears normal, investigate intermittent mechanical resistance and feed behavior rather than assuming oversized clinker is the cause. Correlate motor current with feed surges, crusher speed, vibration, bearing temperature, roll/hammer position, tramp-metal events and downstream discharge. Causes can include localized buildup, foreign material, bearing or coupling drag, damaged crushing elements, intermittent recirculation or a downstream restriction loading the crusher.
Problem / job
Crusher motor current produces short peaks or torque events despite apparently normal incoming clinker size.
Evidence
Capture motor current/torque, crusher speed, vibration, bearing temperatures, feed rate, clinker-size observations, tramp detector events and downstream conveyor load.
Decision
Separate feed surges and foreign objects from local mechanical drag, damaged crusher parts, material buildup and downstream restriction.
As-found evidence capture
Trend each current spike and note its duration, repetition rate and relation to cooler discharge. Observe whether spikes occur randomly or at a repeatable crusher angular position. Record bearing temperatures and vibration before shutdown.
Check downstream conveyor or chute load. A restriction after the crusher can allow material to accumulate around the crushing elements and produce current peaks even though incoming clinker is not oversized.
Seven-step diagnostic workflow
1. Correlate current spikes with feed events
Compare motor current with cooler discharge and any feed-level indication. A short high-density surge can increase torque without a visible change in average clinker size.
2. Check for tramp or foreign material
Review magnetic separator/tramp detector history where installed and inspect safely after isolation. Metallic objects or refractory fragments can create isolated high-torque events.
3. Inspect crushing elements
Check rolls, teeth, hammers or breaker bars according to the crusher design. Look for broken, bent or unevenly worn parts, localized buildup and witness marks that indicate intermittent contact.
4. Check bearings, coupling and drive
Trend bearing temperature and vibration. Inspect coupling condition and alignment. Mechanical drag that changes with rotation can produce current spikes at a consistent frequency.
5. Verify crusher clearances/settings
Confirm mechanical settings and any hydraulic or spring arrangement have not shifted. Unequal or incorrect clearance can cause one zone to carry disproportionate load.
6. Inspect downstream discharge
Check chute, conveyor and transfer point for restriction or buildup. Material packing around the crusher outlet can raise torque even when feed size is acceptable.
7. Verify after correction at representative load
After removing the cause, trend current through steady production. Confirm spikes disappear or return to the accepted baseline while throughput and product size remain normal.
Evidence-to-decision table
| Evidence | Likely direction | Next check |
|---|---|---|
| Random isolated high-current spikes | Tramp material/feed surge | Feed path and foreign-object evidence |
| Spike repeats at fixed rotational frequency | Mechanical contact/drag | Crusher elements, bearings, coupling |
| Current rises with downstream conveyor load | Outlet restriction | Chute and conveyor |
| Current spike plus vibration/temperature rise | Bearing or mechanical damage | Bearing, alignment, rotor condition |
| Normal feed but one crusher side heavily worn | Unequal setting/load distribution | Clearance and element condition |
Use the spike pattern to separate feed torque from rotating mechanical drag
Plot crusher motor current against time and compare each spike with cooler discharge, crusher rotational position where a speed reference exists, vibration and downstream conveyor load. A current peak that follows an irregular clinker surge or isolated tramp event will usually appear at random timing. A peak that repeats at a stable rotational frequency is stronger evidence of a bent or damaged crushing element, localized buildup, bearing/coupling drag or another defect that returns to the loaded position once per revolution.
When the average clinker size looks normal, inspect distribution rather than only the visual average. A short dense bed release, refractory fragment or locally fused clinker piece can create a torque impulse without changing the apparent average size. Preserve any recovered foreign material and compare the event time with upstream cooler operation so the source is not lost after the crusher is cleared.
Field inspection and repeat-failure sequence
- Trend current, speed, vibration and bearing temperatures before shutdown so the fault pattern is preserved.
- Apply full isolation and inspect rolls, teeth, hammers or breaker bars for impact marks, uneven wear, looseness and localized buildup.
- Rotate or index the crusher using the OEM-approved maintenance method and check for a repeatable tight point or mechanical interference.
- Inspect bearings, coupling and drive alignment for evidence of drag or temperature asymmetry.
- Check crusher outlet, chute and downstream conveyor for packing or restriction that can back-load the crushing chamber.
- Review tramp-metal or foreign-object evidence and the cooler-discharge path for refractory or metal sources.
- After correction, repeat the same production condition and verify that peak current behavior, vibration and product size return to the established healthy pattern.
If spikes return after a short period, do not keep resetting protection or widening operating limits. Recheck the same event signature—random versus rotational, feed-linked versus downstream-linked—because repeatability is the fastest route back to the physical cause.
Return-to-service acceptance criteria
Accept the crusher when current/torque remains stable at representative clinker flow, bearings and vibration are normal, crushing elements rotate without abnormal contact, the downstream path is clear and product size remains within the plant target.
Common mistakes
Do not blame clinker size from one visual observation. Do not repeatedly reset overcurrent trips without locating the torque source. Do not enter or inspect the crusher without full isolation. Do not ignore downstream buildup. Finally, trend current frequency; a repeating pattern can identify a mechanical source faster than random dismantling.
