Quick answer
Bags that burst after leaving the cement packer should be diagnosed across the complete fill-and-transfer path: bag quality, fill weight, internal air, drop height, discharge conveyor impact, guides and bag temperature/moisture. A bag can leave the spout intact and fail seconds later if overfilled, poorly vented or struck by a sharp transfer point.
Problem / job
Filled bags split, tear or release cement on the packer discharge conveyor or at the first transfer.
Evidence
Capture failure location, fill weight, bag supplier/batch, drop height, conveyor speed, impact points, bag valve condition and visible tear pattern.
Decision
Separate bag-quality and overfill problems from trapped air, mechanical impact, sharp guides and poor conveyor synchronization.
As-found evidence capture
Do not clean the line before documenting the failure pattern. Mark the exact location where each bag first tears or releases cement and photograph the tear orientation where plant procedure permits. Record filling spout, actual bag weight, bag supplier/batch, valve condition, bag temperature, conveyor speed, drop height and the transfer point where the failure occurs.
Split the defect by location. A bag that fails while still on the packer points toward filling pressure, overfill, bag quality or venting. A bag that leaves the spout intact and tears at the same conveyor/guide point points toward mechanical handling. A bag that swells and bursts on the first drop suggests trapped air or poor bag venting.
Also compare failures by product grade and bag temperature. A product change can alter aeration, fill rate and how much air remains inside the bag at ejection. Keep this separate from bag-material defects so a process change is not incorrectly assigned to the supplier.
Minimum evidence checklist
- Independent bag weight and packer indicated weight for failed and healthy bags.
- Failure rate by filling spout and by bag supplier/batch.
- Tear location: valve, seam, body, corner or impact point.
- Bag inflation/swelling immediately after ejection.
- Drop height and orientation from packer to first conveyor.
- Sharp edges, protruding bolts, damaged guides and transfer gaps.
- Upstream/downstream conveyor speeds and bag spacing.
- Bag storage moisture/condition and any recent bag specification change.
Seven-step workflow
Safety before physical inspection: Stop the packer and affected conveyors, isolate and lock out electrical, pneumatic and mechanical energy sources, release or restrain stored pressure and moving loads, and verify zero-energy state before approaching spouts, guides, transfer points or nip areas. Record operating observations from a guarded, safe position only. Any functional restart or running test must follow the site permit, guarding and authorized commissioning procedure; never reach into moving machinery.
- Map exactly where and how the bag tears; seam, valve and impact tears suggest different causes.
- Compare actual fill weight and variation with the approved target.
- Inspect bag batch quality, paper/laminate condition and storage moisture.
- Check whether excess entrained air causes a swollen bag to burst under impact.
- Measure drop heights and inspect sharp edges, guides and misaligned conveyors.
- Compare conveyor speeds so bags are not compressed or struck at transfers.
- After correction, run a representative bag sample and verify no burst/leak failures through the handling path.
Decision table
Diagnostic decision matrix
| Evidence | Likely direction | Next check |
|---|---|---|
| Failures concentrated in one bag batch | Bag quality/storage | Supplier batch and storage |
| Bags overweight before bursting | Overfill/calibration | Packer weight system |
| Tear occurs at same conveyor edge | Mechanical impact | Guide/transfer geometry |
| Swollen bags fail on first drop | Entrained air/poor venting | Fill aeration and bag valve |
| Bags bunch at transfer | Conveyor speed mismatch | Speed and spacing |
Read the tear pattern before changing the machine
Valve-area split: check bag valve quality, filling pressure, venting and how the bag leaves the spout. Long seam tear: compare bag batch strength and overfill/expansion. Corner or side puncture at one transfer: inspect guides, protrusions, transfer plates and drop geometry. Bag body balloons then bursts: investigate trapped filling air and poor venting before reducing conveyor speed. Random failures across the line: compare bag batch, moisture/storage and packer weight variation before blaming one conveyor.
Track failures by spout and transfer point. If one filling spout produces most swollen or burst bags, inspect that spout’s filling/cut-off/venting behavior. If every spout is healthy until bags reach one physical location, the fault is downstream handling.
Acceptance criteria
Verify the correction through the complete handling path:
- Confirm independent bag weight and variation are inside the approved plant/legal target.
- Run representative bags from multiple filling spouts and the current bag batch.
- Observe ejection, first drop, transfers, guides and conveyor synchronization.
- Confirm bags are not excessively swollen and valves/seams remain intact.
- Check no one transfer point produces repeated tears, abrasion or compression.
- Record failure rate, spout, bag batch and corrected geometry/settings as the new baseline.
Use the packer OEM, bag supplier and plant weight/packaging specification for quantitative limits; do not use a universal impact height or fill-pressure value.
Common mistakes and repeat-failure traps
- Blaming bag quality without mapping the failure point: repeated tears at one guide or transfer are a handling fault until proven otherwise.
- Increasing bag strength to hide overfill: first verify bag weight and packer cut-off.
- Ignoring trapped air: an intact but swollen bag can fail at the first impact because excess filling air has not escaped.
- Slowing every conveyor: speed changes can create bunching; compare transfer speeds and spacing as a system.
- Inspecting only the packer: the fault can be entirely downstream after a healthy filling cycle.
- Changing several variables together: change one proven cause at a time and repeat the same bag route.
