Quick answer
A bearing RTD that exhibits sudden upward or downward jumps while vibration, load and surrounding temperature remain stable is most often an instrumentation fault. Before any mechanical intervention, verify terminal tightness, conductor integrity, proper 3‑wire compensation, shielding, grounding and transmitter or input‑card health. Loose connections, moisture ingress, broken leads, or electrical noise can create abrupt, false temperature spikes.
Problem / job
The process display shows a bearing temperature that changes unrealistically fast, or an alarm trips intermittently, without any corresponding change in vibration, load, or ambient temperature. The maintenance team must determine whether the temperature change reflects actual bearing heating or a faulty measurement chain.
Evidence
Collect the raw RTD reading, the trend from any nearby temperature sensor, vibration and load data, the status of the input channel (e.g., fault flags), and visual condition of the wiring and terminals. Note whether the temperature jump coincides with cable movement, equipment start‑up, or any other observable event.
Decision
Separate a genuine bearing over‑temperature from faults in the RTD element, lead‑wire, terminal block, transmitter, or PLC/DCS input module. The decision path follows a structured seven‑step workflow that isolates each part of the measurement loop.
Seven‑step diagnostic workflow
1. Verify plausibility of the temperature change
Compare the observed rate of change with the thermal mass of the bearing, its operating load, and the temperature gradient of adjacent sensors. A bearing cannot heat or cool by tens of degrees in a few seconds; such a rapid shift points to an electrical anomaly. Document the magnitude and duration of the jump and cross‑reference it with vibration and load logs.
2. Corroborate with independent temperature evidence
Where safe, obtain a second temperature measurement. Options include an approved non-intrusive infrared measurement made from a protected observation point, an existing independent bearing-housing RTD measured from a safe location, or a thermocouple that is part of a different instrumentation loop. If the independent reading follows the same trend, the temperature change is likely real; if not, the fault resides in the primary RTD circuit.
3. Isolate the measurement loop with proper lock‑out/tag‑out (LOTO)
Before opening any junction box or disconnecting conductors, apply LOTO in accordance with plant procedures. De‑energize the relevant power supply, apply the required lockout/tagout devices, and then verify absence of voltage using an appropriately rated tester under the plant’s approved procedure. Only then inspect terminal screws, corrosion, and physical condition of the RTD leads. Loose or oxidised terminals are a common source of intermittent resistance spikes.
4. Test the 3‑wire (or 4‑wire) compensation network
Measure the resistance of each lead individually with a portable ohmmeter while the circuit remains isolated. A broken compensation lead will cause the transmitter to interpret the remaining lead resistance as a temperature change. Follow the OEM’s wiring verification procedure: check for continuity, verify that the lead‑wire resistance is within the specified tolerance, and confirm that the bridge balance is correct.
5. Inspect cable routing and electromagnetic environment
Examine the routing of the RTD cable for proximity to variable‑frequency drives, high‑current motor leads, or other sources of electromagnetic interference (EMI). Verify that shielding is intact, the shield is terminated correctly (usually at the transmitter end), and that the cable is supported to prevent movement. Cable motion that coincides with temperature jumps strongly suggests a mechanical‑electrical coupling fault.
6. Substitute the sensor or input channel
With the circuit safely isolated and under an approved instrument-testing procedure, use a calibrated RTD simulator or verified substitute sensor to test the measurement chain. Test the sensor, field wiring, transmitter and PLC/DCS input separately, checking configuration and diagnostic flags. Do not replace a transmitter or input card solely because a symptom persists after one substitution; confirm the defective component through appropriate isolation and comparison tests. Document the results and retain suspect components for analysis.
7. Validate a stable trend before returning to service
After corrective actions, complete authorized lockout/tagout removal before controlled re‑energization, and monitor the temperature trend through a full operating cycle, including start‑up, normal load, and shutdown. Confirm that the trend is smooth, that alarm thresholds trigger only on genuine excursions, and that no unexplained spikes appear when the bearing is subjected to typical vibration or load variations.
Evidence‑to‑decision matrix
| Evidence | Likely direction | Next check |
|---|---|---|
| Instant temperature jump with unchanged vibration, load, and ambient temperature | Instrumentation fault | Inspect terminals, wiring, and input module |
| Jump occurs only when cable or conduit is moved | Loose or broken conductor | Secure terminal connections; test lead continuity |
| Multiple nearby RTDs exhibit simultaneous jumps | Common power, grounding, or EMI issue | Review shielding, grounding scheme, and power distribution |
| Independent temperature sensor confirms the same rise | Actual bearing heating | Proceed to mechanical/lubrication root‑cause analysis |
| Transmitter fault flag or diagnostic code appears | Transmitter or input‑card malfunction | Swap transmitter or replace input module |
Return‑to‑service acceptance criteria
Release the bearing to service only when the following measurable conditions are satisfied:
- Temperature trend is stable within the expected measurement noise and instrument accuracy, without unexplained step changes or intermittent fault flags; its rate of change is physically plausible for the bearing and operating conditions.
- All terminal screws are torqued to the OEM‑specified value, and visual inspection shows no corrosion or damaged conductors.
- Lead‑wire resistance measurements are within the manufacturer’s tolerance for each leg of the compensation network.
- Agreement with an independent temperature measurement is within the combined uncertainty of the instruments and the OEM/plant acceptance tolerance, accounting for measurement location and operating conditions.
- Alarm set‑points trigger only when the temperature exceeds the defined limit for a duration specified by the process control strategy.
- Before removing LOTO, confirm that testing and physical work are complete, all conductors and enclosures are secured, safeguards are restored, and personnel are clear. Only authorized personnel may remove LOTO in accordance with plant procedures. Then re-energize the loop and verify a stable trend, correct alarm behavior, and absence of fault flags before return to service.
Common mistakes and repeat‑failure traps
- Skipping LOTO. Opening a junction box while the circuit is live can cause arcing, further damage the terminals, and expose personnel to shock. Always follow lock‑out procedures before any physical inspection.
- Assuming a temperature jump is mechanical. Relying solely on vibration data without confirming electrical integrity leads to unnecessary bearing disassembly and downtime.
- Replacing the RTD without verifying the wiring. A new sensor will inherit the same loose or broken lead if the underlying cable is not inspected, resulting in recurring false alarms.
- Neglecting shielding and grounding. In high‑EMI environments, an improperly terminated shield can inject noise that mimics temperature spikes. Re‑establish proper grounding before concluding the loop is sound.
- Over‑tightening terminal screws. Excessive torque can strip threads or crack the terminal block, creating intermittent contact that re‑appears after vibration.
- Failing to document each step. Without a clear record of checks, substitutions, and measurements, future troubleshooting may repeat the same actions, extending outage time.
