Calculation Formulas for Process Fans

Electrical Power Requirement for Fan

The required electrical power can be calculated as:

Total Pressure Increase (Rough Estimation)

The total pressure increase p of a fan can be calculated as:

Influence of Fan Speed on Volume flow, Static Pressure and Power Consumption:

The volume flow depends on the fan speed as:

The static pressure depends on the fan speed as:

The electrical power requirement depends on the fan speed as:
