Quick answer
A repeated hopper high-level alarm after an emptying cycle can come from retained material, a blocked discharge path, sensor contamination, signal/wiring faults, or control-logic configuration. First verify the actual material level safely, then check discharge equipment and the level instrument against OEM/site documentation. Correct the evidenced cause rather than assuming the sensor is faulty.
Problem / Job
The bag filter hopper repeatedly triggers a high‑level alarm even after the automatic emptying cycle has completed. The alarm prevents the plant from proceeding to the next batch, causing downtime and reduced throughput.
Evidence to collect
- Compare the indicated hopper level with a safe, independent confirmation of the actual material condition.
- Record whether the alarm appears before, during, or after the discharge cycle and whether material is actually leaving the hopper.
- Capture the instrument indication, PLC input value, alarm state, and relevant event timestamps without assuming any value is correct.
- Inspect for retained material, bridging, discharge restriction, sensor contamination, wiring defects, or recent maintenance changes.
- Use the installed instrument manual, drawings, and site logic documentation as the acceptance reference.
Decision
Proceed with a systematic diagnostic sequence that isolates the sensor, verifies signal integrity, checks transmitter configuration, and validates the control logic. Replace or recalibrate the sensor only after confirming that wiring, power, and signal conditioning are within OEM specifications.
7‑Step Diagnostic Workflow
- Secure the work under the plant’s approved isolation procedure. Identify all relevant electrical, pneumatic, mechanical, stored-energy, and process hazards; apply the site’s authorized LOTO/isolation procedure and verify the safe state using the approved method before inspection or testing. Do not prescribe an isolation boundary from this guide.
- Document the current alarm state. Capture the PLC alarm timestamp, alarm ID, and any associated event logs. Take a screenshot of the HMI alarm panel.
- Perform a manual level verification. Use a calibrated staff gauge or laser level rod to measure the actual material height in the hopper. Record the measurement and compare it to the sensor’s displayed value.
- Inspect the sensor physically. Remove any dust, bag debris, or condensation from the sensor’s window. Verify that the sensor is mounted at the correct angle and distance as per the OEM installation drawing.
- Check wiring and terminations. Follow the OEM wiring diagram to confirm that power, ground, and signal conductors are correctly terminated. Look for loose connectors, corrosion, or damaged insulation.
- Validate transmitter output. With the sensor powered, use a calibrated multimeter or handheld process calibrator to measure the transmitter’s 4‑20 mA (or 0‑10 V) output at known level points (empty, half‑full, full). Compare the measured values to the OEM’s calibration curve.
- Review control logic. Open the PLC program and verify that the high‑level alarm setpoint, hysteresis, and reset conditions match the design intent. Ensure that the emptying cycle logic does not inadvertently re‑assert the alarm.
After each step, record findings and decide whether to proceed to the next step or to implement corrective action.
Diagnostic Matrix
| Evidence | Likely Direction | Next Check |
|---|---|---|
| Sensor reads high while manual gauge shows low. | Sensor obstruction or calibration drift. | Clean sensor window and repeat manual verification. |
| Signal output does not change with level. | Transmitter fault or power supply issue. | Measure transmitter 4‑20 mA (or 0‑10 V) at power terminals. |
| Wiring shows loose or corroded connections. | Intermittent signal causing false high reading. | Re‑terminate connectors and retest output. |
| PLC alarm setpoint is lower than design. | Control logic mis‑configuration. | Compare setpoint to OEM design documentation and adjust. |
| Hopper vibration or bag movement during emptying. | Transient splash or bag flutter causing momentary high reading. | Observe sensor response during a controlled emptying cycle. |
| Power supply voltage deviates from OEM spec. | Transmitter may be out of range, producing erroneous output. | Verify power supply with a calibrated meter; adjust or replace supply. |
Verification & Acceptance Criteria
- After cleaning or recalibration, verify that the sensor reports the expected empty-state indication when the independently confirmed hopper level meets the site/OEM-defined empty condition.
- The transmitter output must follow the OEM‑provided calibration curve within the tolerance specified in the OEM documentation. Verify at least three points: empty, mid‑level, and full.
- The PLC high‑level alarm must not trigger when the measured level is below the configured setpoint plus hysteresis. Confirm by running a full empty‑to‑fill cycle and observing the alarm status.
- All wiring connections must be torque‑checked and free of corrosion. Document the torque values as per OEM recommendations.
- LOTO tags must be removed only after functional testing confirms normal operation and the alarm is cleared without manual reset.
Common Mistakes & Repeat‑Failure Traps
- Skipping LOTO. Working on live instrumentation can cause intermittent faults that mask the true problem and create safety hazards.
- Cleaning without re‑calibration. Removing debris may change the sensor’s distance to the material surface; a post‑cleaning calibration check is essential.
- Replacing the sensor without confirming wiring. A new sensor will inherit any existing wiring faults, leading to repeated alarms.
- Adjusting PLC setpoints without OEM reference. Lowering the high‑level setpoint to “make the alarm go away” defeats process safety and can cause over‑fill conditions.
- Ignoring transient spikes. Bag movement during emptying can produce brief high‑level spikes; failing to filter or debounce the signal may cause false alarms.
- Assuming a single cause. High‑level repeats often involve a combination of sensor drift, wiring issues, and control logic. A systematic approach prevents premature part replacement.
